Assembly and connecting
Embedded PC 97
PC Health Status
This menu is used for displaying the settings for CPU and motherboard temperatures, power supply, and fan speed.
Phoenix - AwardBIOS CMOS Setup Utility
PC Health Status
Temp. Board CX1020 51°C Item Help
Temp. CPU CX1020 70°C
Temp. Board CX1021 57°C
Temp. Board CX1021
* 60°C
12V * 12.75V
+3.3 V 3.39V
+5 V 5.29V
Fan1 Speed 0
Fan2 Speed 0
VBatt 3.24V
CX1020 Revision * 2
CX1021 Revision * 2
↑ ↓ → ← :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
The * marked items are only shown in HW Version > 2.1 and Bios Version > 2.03.
Temp. Board CX1020
Temperature of the CX1020 motherboard. The maximum operating temperature is 80°C. A warning should be given,
if temperature rises higher than 80° C. If the temperature rises higher than 85° C the system should be shut down.
The position of the sensors is shown in diagram below.
Temp. CPU CX1020
Temperature of the CPU.
The maximum operating temperature is 85°C. A warning should be given, if temperature rises higher than 85° C. If
the temperature rises higher than 95° C the system should be shut down. The position of the sensors is shown in
diagram below.
Temp. Board CX1021
Temperature sensor 1 of the CF board (CX1021) of the CX1020. The maximum operating temperature is 80°C. A
warning should be given, if temperature rises higher than 80° C. If the temperature rises higher than 85° C the
system should be shut down. The position of the sensors is shown in diagram below.
Temp. Board CX1021
Temperature sensor 2 of the CF board (CX1021) of the CX1020. The maximum operating temperature is 80°C. A
warning should be given, if temperature rises higher than 80° C. If the temperature rises higher than 85° C the
system should be shut down. The position of the sensors is shown in diagram below. (This sensor was build for
internal use, it could be used for as alternative to sensor 1)
+12 V
Supply voltage, 12 V.
+3.3 V
Supply voltage, 3.3 V.
+5 V
Supply voltage, 5 V.
