Beckhoff CX1020 Series User Manual

Product overview
Embedded PC 57
LC Display
The LC Display of the power supply units has two rows of 16 characters each and is used for displaying system and
user messages.
"Index-Group/Offset" Specification for the LC Display
ADS Port 300
Index
Group Index Offset Access
Data
type
Phys.
unit
Def.
range Description Remarks
0x00005000
+ DeviceID
0xFFFF90FF R&W
Cursor OFF
0x00005000
+ DeviceID
0xFFFF91FF R&W
Cursor ON
0x00005000
+ DeviceID
0xFFFF92FF R&W
Cursor blink
OFF
0x00005000
+ DeviceID
0xFFFF93FF R&W
Cursor blink ON
0x00005000
+ DeviceID
0xFFFF94FF R&W
Display OFF
0x00005000
+ DeviceID
0xFFFF95FF R&W
Display ON
0x00005000
+ DeviceID
0xFFFF96FF R&W
Backlight OFF
0x00005000
+ DeviceID
0xFFFF97FF R&W
Backlight ON
0x00005000
+ DeviceID
0xFFFFA0FF R&W
Write Text line 1
0x00005000
+ DeviceID
0xFFFF00FF R&W
Write Text line 2
