Assembly and connecting
Embedded PC 85
CPU Features
This menu is used for setting the CPU behaviour with thermal profiles.
Phoenix – AwardBIOS CMOS Setup Utility
CPU Feature
Thermal Management Thermal Monitor 1 Item Help
Delay Prior to Thermal [Disabled]
Execute Disable bit [Enabled]
↑ ↓ → ← :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Thermal Management
The processor used has a thermal monitor. The profile is preset and cannot be changed.
Delay Prior to Thermal
The following options are available: 4, 8, 16 or 32 minutes. This option is only applicable for systems with 0.13µ Intel
Pentium 4 processors with 512 KB L2 cache. These processors come with a thermal monitor consisting of a thermal
sensor and a thermal control circuit (TCC). Once the thermal sensor detects that the processor has reached its
maximum safe operating temperature, the TCC is activated and clocking is reduced to 50-70%. This parameter
should be set to 4 minutes, unless the PC needs longer for booting, in which case a suitable higher value should be
used.
Execute Disable bit
This setting option is only available for certain processors with Execute Disable Bit (XD bit) function. If this option is
set to [Enabled] (activated), the processor can classify areas in memory by where application code can execute and
where it cannot, thereby protecting your memory.
