Assembly and connecting
Embedded PC 71
3. Install cover
If the connection area does not have a closing cover on the left-hand side, the cover that was previously removed
should be pressed over the connections until it audibly engages.
Note:
If the CX1000/CX1020 configuration is not positioned on the top-hat rail, it is possible to connect the assembly with
the CX1000/CX1020 configuration first and then latch the whole module onto the top-hat rail. The installation is
described in section Installation and wiring.
Note:
A locking mechanism prevents the individual housings from being pulled off again.
