Assembly and connecting

Embedded PC 93

9, 10, 11

Suspend Mode

In User Define mode a hold time can be set here. The following values are available: Disable (off) 1 Min , 2 Min , 4

Min, 8 Min , 12 Min , 20 Min , 30Min , 40 Min , 1 Hour. The setting in Min Saving mode is 1 minute. With Max Saving

the hold time is set to 1 hour.

HDD Power Down

Here you can specify after which period of inactivity the hard disk is switched off. This option is only available for IDE

hard disks. Settings: Disabled or 1 to 15 minutes. This option should be used with caution, since frequent switching

on and off is more damaging to the hard disk than beneficial in terms of energy saving.

Wake-Up by PCI card

This option can be used to start your PC from another PC via a network by sending a wake-up frame or signal.

Power On by Ring

The system starts when the phone rings, if an external modem is connected to the onboard serial port.

** Reload Global Timer Events **

Primary IDE 0

If this option is enabled, the system activates the energy-saving timer if no activity is detected on the first drive of the

first IDE/EIDE port. Setting options: Enabled, Disabled

Primary IDE 1

If this option is enabled, the system activates the energy-saving timer if no activity is detected on the second drive of

the first IDE/EIDE port. Setting options: Enabled, Disabled.

Secondary IDE 0

If this option is enabled, the system activates the energy-saving timer if no activity is detected on the first drive of the

second IDE/EIDE port. Setting options: Enabled, Disabled

Secondary IDE 1

If this option is enabled, the system activates the energy-saving timer if no activity is detected on the second drive of

the second IDE/EIDE port. Setting options: Enabled, Disabled

FDD, COM, LPT Port

If one of these menu items is set to "Monitor", the AMI-BIOS monitors the IRQ of the respective connection or device

(and therefore the connection or device itself) for activity while in energy-saving mode. If activity is detected, the

system switches from the respective energy-saving mode to normal mode. The AMI-BIOS resets the standby and

suspend idle time to zero if activity is detected on a specified IRQ.

PCI PIRQ[A-D]#

This option can be used to influence the power management timing. If the option is enabled, a countdown

commences that is interrupted as soon as the INTA~INTD signal becomes active. The system is reset to zero.
