Beckhoff EL10 Series User Manual

Product overview
EL10xx, EL11xx18 Version: 4.5
2.1.4 EL1002, EL1004-00x0, EL1008 - Technical data
Technical data EL1002 EL1004 EL1004-0020 EL1008
Number of inputs 2 4 8
Number of simultaneously controllable in-
puts, depending on the ambient tempera-
ture
2 (> +55°C ) 4(-25°C ... +55°C)
2 (> +55°C )
8(-25°C ... +55°C)
4 (> +55°C )
(aligned in horizontal
installation position)
[}44]
Nominal voltage of the inputs 24V
DC
(-15%/ +20%)
Signal voltage "0" -3V ... 5V (EN61131-2, type 1/3)
Signal voltage "1" 11V ... 30V (EN61131-2, type 1/3)
Input filter 3ms
Input current typically 3mA (EN 61131-2, type 1/3)
Current consumption power contacts typ. 2mA + load
Current consumption via E-bus typ. 90mA
Electrical isolation 500V (E-bus/field voltage) 2500V functional iso-
lation (test voltage E-
bus / field voltage,
production test).
500V (E-bus/field volt-
age)
Bit width in the process image 2 input bits 4 input bits 8 input bits
Configuration no address setting, configuration via TwinCAT System Manager
Weight approx. 55g
Permissible ambient temperature range
during operation
-25°C ... +60°C
(extended temperature range)
0°C ... +55°C -25°C ... +60°C
(extended temperature
range,
aligned in horizontal in-
stallation position
[}44])
-25°C ... +45°C
(all other installation
positions [}44])
Permissible ambient temperature range
during storage
-40°C ... +85°C -25°C ... +85°C -40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15mm x 100mm x 70mm (width aligned: 12mm)
Mounting [}41]
on 35mm mounting rail conforms to EN 60715
Vibration/shock resistance according to EN 60068-2-6/EN 60068-2-27,
see also Installation instructions for termi-
nals with increased mechanical load capac-
ity [}46]
according to EN
60068-2-6/EN
60068-2-27
according to EN
60068-2-6/EN
60068-2-27,
see also Installation in-
structions for terminals
with increased mechani-
cal load capacity [}46]
EMC resistance burst/ESD conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
see note [}44]
Approval
CE, cULus [}53], ATEX [}52], IECEx CE, cULus [}53] CE, cULus [}53], ATEX
[}52], IECEx
