Beckhoff EL10 Series User Manual

Product overview
EL10xx, EL11xx30 Version: 4.5
2.5.2 EL1104, EL1114 - Technical data
Technical data EL1104 EL1114
Number of inputs 4
Number of simultaneously controllable inputs, de-
pending on the ambient temperature
4 (-25°C ... +55°C)
2 (> +55°C )
4 (0°C ... + 55°C)
Nominal voltage of the inputs 24V
DC
(-15%/ +20%)
Signal voltage "0" -3V ... 5V (EN 61131-2, type 1/3)
Signal voltage "1" 11V ... 30V (EN 61131-2, type 1/3)
Input filter 3ms 10µs typ. (10...50 µs)
Input current typically 3mA (EN 61131-2, type 1/3)
Current consumption power contacts typ. 2mA + load
Current consumption from the E-bus typ. 90mA
Electrical isolation 500V (E-bus/field voltage)
Bit width in the process image 4 input bits
Configuration no address setting, configuration via TwinCAT System Manager
Weight approx. 55g
Permissible ambient temperature range during op-
eration
-25°C ... +60°C
(extended temperature range)
0°C ... + 55°C
Permissible ambient temperature range during
storage
-40°C ... +85°C -25°C ... + 85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15mm x 100mm x 70mm (width aligned: 12mm)
Mounting [}41]
on 35mm mounting rail conforms to EN 60715
Vibration/shock resistance according to EN 60068-2-6/EN 60068-2-27,
see also Installation instructions for terminals with increased mechanical load ca-
pacity [}46]
EMC resistance burst/ESD conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval
CE, cULus [}53], ATEX [}52] CE, cULus [}53], ATEX [}51]
