2.2.4 EL1012, EL1014, EL1018 - Technical data
Technical data EL1012 EL1014 EL1018
Number of imputs 2 4 8
Number of simultaneously controllable in-
puts, depending on the ambient tempera-
ture
2 (> +55°C ) 4(-25°C ... +55°C)
2 (> +55°C )
8(-25°C ... +55°C)
4 (> +55°C )
(aligned in horizontal installa-
tion position) [}44]
Nominal voltage of the inputs 24V
DC
(-15%/ +20%)
Signal voltage "0" -3V ...5V (EN61131-2, type 1/3)
Signal voltage "1" 11V ... 30V (EN61131-2, type 1/3)
Input filter 10µs typ. (10...50µs)
Input current typically 3 mA (EN 61131-2, type 1/3)
Current consumption power contacts typ. 2mA + load
Current consumption via E-bus typ. 90mA typ. 90mA typ. 90mA
Electrical isolation 500V (E-bus/field voltage)
Bit width in the process image 2 input bits 4 input bits 8 input bits
Configuration no address setting, configuration via TwinCAT System Manager
Weight approx. 55g
Permissible ambient temperature range
during operation
-25°C ... +60°C
(extended temperature range)
-25°C ... +60°C
(extended temperature range,
aligned in horizontal installa-
tion position [}44])
-25°C ... +45°C
(all other installation positions
[}44])
Permissible ambient temperature range
during storage
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15mm x 100mm x 70mm (width aligned: 12 mm)
Mounting [}41]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance according to EN 60068-2-6/EN 60068-2-27,
see also Installation instructions for terminals with increased mechanical load capacity
[}46]
EMC resistance burst/ESD conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
see note [}44]
Approval
CE, cULus [}53], ATEX [}52]
