Beckhoff EL10 Series User Manual

Product overview
EL10xx, EL11xx 25Version: 4.5
EL1034 - Connection
Terminal point Description
Name No.
Input 1 1 Input 1
GND 1 2 Ground (GND) 1
GND 3 3 Ground (GND) 3
Input 3 4 Input 3
Input 2 5 Input 2
GND 2 6 Ground (GND) 2
GND 4 7 Ground (GND) 4
Input 4 8 Input 4
2.3.3 EL1024, EL1034 - Technical data
Technical data EL1024 EL1034
Number of inputs 4 4 (potential-free)
Nominal voltage of the inputs 24V
DC
(-15%/ +20%)
Signal voltage "0" -3V ... 5V (EN61131-2, type 2) -3V ... 5V (EN61131-2, type 1)
Signal voltage "1" 11V ... 30V (EN61131-2, type 2) 15V ... 30V (EN61131-2, type 1)
Input filter 3ms 10µs
Input current typically 6mA (EN 61131-2, type 2) typically 3mA (EN 61131-2, type 1)
Current consumption power contacts typ. 30 mA + load -
Current consumption via E-bus typ. 90mA
Electrical isolation 500V (E-bus/field voltage)
Bit width in the process image 4 input bits
Configuration no address setting, configuration via TwinCAT System Manager
Weight approx. 55g
Permissible ambient temperature range during op-
eration
0°C ... + 55°C
Permissible ambient temperature range during
storage
-25°C ... + 85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15mm x 100mm x 70mm (width aligned: 12mm)
Mounting [}41]
on 35mm mounting rail conforms to EN 60715
Vibration/shock resistance according to EN 60068-2-6/EN 60068-2-27,
see also Installation instructions for terminals with increased mechanical load ca-
pacity [}46]
EMC resistance burst/ESD conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval
CE, cULus [}53], ATEX [}51]
