Beckhoff EL10 Series User Manual

Product overview
EL10xx, EL11xx28 Version: 4.5
2.4.3 EL1084, EL1088, EL1094, EL1098 - Technical data
Technical data EL1084 EL1088 EL1094 EL1098
Number of inputs 4 8 4 8
Nominal voltage of the inputs 24V
DC
(-15%/ +20%)
Signal voltage "0" 18V ... 30V
Signal voltage "1" 0V ... 7V
Input filter 3ms 3ms 10µs 10µs
Input current typ. 3mA
Current consumption power contacts typ. 20mA typ. 25mA typ. 20mA typ. 25mA
Current consumption via E-bus typ. 90mA
Electrical isolation 500V (E-bus/field voltage)
Bit width in the process image 4 input bits 8 input bits 4 input bits 8 input bits
Configuration no address setting, configuration via TwinCAT System Manager
Weight approx. 55g
Permissible ambient temperature
range during operation
0°C ... + 55°C 0°C ... + 55°C
(aligned in horizontal
installation position)
0°C ... + 45°C
(all other installation
positions,
see Note [}44])
0°C ... + 55°C 0°C ... + 55°C
(aligned in horizontal
installation position)
0°C ... + 45°C
(all other installation
positions,
see Note [}44])
Permissible ambient temperature
range during storage
-25°C ... + 85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}41]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance according to EN 60068-2-6/EN 60068-2-27,
see also Installation instructions for terminals with increased mechanical load capacity
[}46]
EMC resistance burst/ESD conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP 20
Installation position variable
see note [}44]
variable
see note [}44]
Approval
CE, cULus [}53], ATEX [}51]
