Beckhoff TwinSAFE logic FB

Function blocks
136 Function blocks for TwinSAFE logic components
3.19.2 Signal description
Table 3-113: FB DIV inputs
Name
Permitted type
Data type
Description
AnalogIn1
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
INT16
INT32
UINT16
UINT32
1st input channel for division
AnalogIn2
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
INT16
INT32
UINT16
UINT32
2nd input channel for division
Table 3-114: FB DIV outputs
Name
Permitted type
Data type
Description
Error
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Error output (see diagnostic information)
AnalogOut
TwinSAFE-Out
FB-In
Standard-Out
INT16
INT32
UINT16
UINT32
1st output channel with the division result
Table 3-115: Input and output types
Type
Description
TwinSAFE-In
TwinSAFE input of an EL1904/KL1904, e.g.
Standard-In
Standard PLC variable (output in the PLC %Q*)
FB-Out
TwinSAFE FB output
TwinSAFE-Out
TwinSAFE output of an EL2904/KL2904, e.g.
Standard-Out
Standard PLC variable (input in the PLC %I*)
FB-In
TwinSAFE FB input
TwinSAFE SC
Input of a TwinSAFE connection (TwinSAFE SC technology)
Table 3-116: Internal identifier of the FB
Type
Description
FB DIV
This description applies to BLG 1.0 (internal version number)
