Beckhoff TwinSAFE logic FB User Manual

Function blocks
Function blocks for TwinSAFE logic components 153
3.23.2 Signal description
Table 3-141: FB Scale inputs
Name
Permitted type
Data type
Description
AnalogIn1
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
INT16
INT32
UINT16
UINT32
Input for scaling.
Table 3-142: FB Scale outputs
Name
Permitted type
Data type
Description
Error
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Error output (see diagnostic information)
StuckAtError
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output that is set if the AnalogIn input remains
unchanged over the parameterized period
AnalogOut
TwinSAFE-Out
FB-In
Standard-Out
INT16
INT32
UINT16
UINT32
Output with the scaled input signal
Processing order:
• AnalogIn negation
• Nominator multiplication scaling factor
(configurable)
• Denominator division scaling factor
(configurable)
• Addition scaling offset
Table 3-143: Input and output types
Type
Description
TwinSAFE-In
TwinSAFE input of an EL1904/KL1904, e.g.
Standard-In
Standard PLC variable (output in the PLC %Q*)
FB-Out
TwinSAFE FB output
TwinSAFE-Out
TwinSAFE output of an EL2904/KL2904, e.g.
Standard-Out
Standard PLC variable (input in the PLC %I*)
FB-In
TwinSAFE FB input
TwinSAFE SC
Input of a TwinSAFE connection (TwinSAFE SC technology)
Table 3-144: Internal identifier of the FB
Type
Description
FB SCALE
This description applies to BLG 1.0 (internal version number)
3.23.2.1 Diagnostic and state information for the FB Scale1
Table 3-145: Diagnostic information
Value
Description
0
No diagnostic information
1
The AnalogOut output has an underflow (is less than the smallest possible value)
2
The AnalogOut output has an overflow (is greater than the largest possible value)
3
A 32-bit overflow occurred during the multiplication.
4
A 32-bit overflow occurred during the division due to rounding.
