Function blocks
Function blocks for TwinSAFE logic components 31
3.2.2 Signal description
Table 3-7: FB OR inputs
Name
Permitted type
Data type
Description
OrIn1
TwinSAFE-In
FB-Out
BOOL
1st input channel
OrIn2
TwinSAFE-In
FB-Out
BOOL
2nd input channel
OrIn3
TwinSAFE-In
FB-Out
BOOL
3rd input channel
OrIn4
TwinSAFE-In
FB-Out
BOOL
4th input channel
OrIn5
TwinSAFE-In
FB-Out
BOOL
5th input channel
OrIn6
TwinSAFE-In
FB-Out
BOOL
6th input channel
OrIn7
TwinSAFE-In
FB-Out
BOOL
7th input channel
OrIn8
TwinSAFE-In
FB-Out
BOOL
8th input channel
Table 3-8: FB OR outputs
Name
Permitted type
Data type
Description
OrOut
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
Output channel
Table 3-9: Input and output types
Type
Description
TwinSAFE-In
TwinSAFE input, e.g. at an EL1904/KL1904
Standard-In
Standard PLC variable (output in the PLC %Q*)
FB-Out
TwinSAFE FB output
TwinSAFE-Out
TwinSAFE output, e.g. at an EL2904/KL2904
Standard-Out
Standard PLC variable (input in the PLC %I*)
FB-In
TwinSAFE FB input
Local-Out
TwinSAFE output at the KL6904 (not available for EL6900)
Table 3-10: Internal identifier of the FB
Type
Description
FB OR
This description applies to BLG 1.0 (internal version number)
