Function blocks
156 Function blocks for TwinSAFE logic components
A mouse click next to the FB Port, here AnalogIn, Error, StuckAtError and AnalogOut, can be used to
create variables that can be linked to input or output signals. Settings such as changing the data type or
activation of the input can be made via the properties of the FB port.
The MapState and MapDiag entries define which diagnostic functions of the FB are mapped to the cyclic
process image.
