Beckhoff TwinSAFE logic FB User Manual

Function blocks
Function blocks for TwinSAFE logic components 163
Table 3-156: FB LoadSensing outputs
Name
Permitted type
Data type
Description
Valid
TwinSAFE-Out
FB-In
Standard-Out
BOOL
This output is set if AnalogInY is within the switch-
off level.
Warning
TwinSAFE-Out
FB-In
Standard-Out
BOOL
This output is set if AnalogInY is between the
switch-off level and the warning level.
Table 3-157: Input and output types
Type
Description
TwinSAFE-In
TwinSAFE input of an EL1904/KL1904, e.g.
Standard-In
Standard PLC variable (output in the PLC %Q*)
FB-Out
TwinSAFE FB output
TwinSAFE-Out
TwinSAFE output of an EL2904/KL2904, e.g.
Standard-Out
Standard PLC variable (input in the PLC %I*)
FB-In
TwinSAFE FB input
TwinSAFE SC
Input of a TwinSAFE connection (TwinSAFE SC technology)
Table 3-158: Internal identifier of the FB
Type
Description
FB LoadSensing
This description applies to BLG 1.0 (internal version number)
3.25.2.1 Diagnostic and state information for the FB LoadSensing
Table 3-159: Diagnostic information
Value
Description
-
No diagnostic information
Table 3-160: Diag Message
Text ID
Meaning
Parameter 1
Parameter 2
Parameter 3
-
-
-
-
-
