Beckhoff TwinSAFE logic FB User Manual

Function blocks
208 Function blocks for TwinSAFE logic components
3.29.2.1 Diagnostic and state information for the FB ViolationCnt
Table 3-184: Diagnostic information
Value
Description
0
no diagnostic information
Table 3-185: Diag Message
Text ID
Meaning
Parameter 1
Parameter 2
Parameter 3
-
-
-
-
-
Table 3-186: State information
Value
Description
1
RUN
If the input Enable is TRUE and LimitOverrun is FALSE, the FB VIOCNT module
assumes the RUN state and modifies the ActViolationCnt value.
The outputs assume the following values:
InputOK=1
ActViolationCnt = current value
2
STOP
The FB VIOCNT module assumes the STOP state if the input FbRun is FALSE.
The outputs assume the following values:
InputOK=0
ActViolationCnt = 0
3
SAFE
If the input Enable is TRUE and LimitOverrun is TRUE, the FB VIOCNT module
assumes the SAFE state and modifies the ActViolationCnt value.
The outputs assume the following values:
InputOK=0
ActViolationCnt = current value
6
START
If the input Enable is FALSE, the FB VIOCNT module assumes the START state.
The outputs assume the following values:
InputOK=0
ActViolationCnt = 0
