Beckhoff TwinSAFE logic FB

Function blocks
212 Function blocks for TwinSAFE logic components
Table 3-188: FB XOR outputs
Name
Permitted
type
Data
type
Description
XorOut1
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output of XOR1
XorOut2
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output of XOR2
XorOut3
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output of XOR3
XorOut4
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output of XOR4
XorOut5
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output of XOR5
XorOut6
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output of XOR6
XorOut7
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output of XOR7
XorOut8
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output of XOR8
Table 3-189: Input and output types
Type
Description
TwinSAFE-In
TwinSAFE input of an EL1904/KL1904, e.g.
Standard-In
Standard PLC variable (output in the PLC %Q*)
FB-Out
TwinSAFE FB output
TwinSAFE-Out
TwinSAFE output of an EL2904/KL2904, e.g.
Standard-Out
Standard PLC variable (input in the PLC %I*)
FB-In
TwinSAFE FB input
TwinSAFE SC
Input of a TwinSAFE connection (TwinSAFE SC technology)
Table 3-190: Internal identifier of the FB
Type
Description
FB XOR
This description applies to BLG 1.0 / BLG 2.0 (internal version number)
3.30.2.1 Diagnostic and state information for FB XOR
Table 3-191: Diagnostic information
Value
Description
0
no diagnostic information
Table 3-192: Diag Message
Text ID
Meaning
Parameter 1
Parameter 2
Parameter 3
-
-
-
-
-
