Table 3-14: Outputs of the FB OPMODE
Name
Permitted type
Data
type
Description
Error
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
TRUE:
The discrepancy time monitoring or the input monitoring
has found an error. The acknowledgement of the error
must be carried out via the ERR_ACK input of the
related TwinSAFE group
FALSE:
No error was found.
OpOut1
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
1st output channel
OpOut2
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
2nd output channel
OpOut3
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
3rd output channel
OpOut4
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
4th output channel
OpOut5
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
5th output channel
OpOut6
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
6th output channel
OpOut7
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
7th output channel
OpOut8
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
8th output channel
