Function blocks
Function blocks for TwinSAFE logic components 47
3.4.2.1 Diagnostic and state information for FB ESTOP
Table 3-23: Diagnostic information (16-bit value)
Bit
Description
0
Discrepancy error input group 1
1
Discrepancy error input group 2
2
Discrepancy error input group 3
3
Discrepancy error input group 4
4
EDM monitoring error EDM1
5
EDM monitoring error EDM2
6
-
7
-
8
Discrepancy error input group 1 with activated option "Safe Inputs after Disc Error"
(set in addition to bit 0)
9
Discrepancy error input group 2 with activated option "Safe Inputs after Disc Error"
(set in addition to bit 1)
10
Discrepancy error input group 3 with activated option "Safe Inputs after Disc Error"
(set in addition to bit 2)
11
Discrepancy error input group 4 with activated option "Safe Inputs after Disc Error"
(set in addition to bit 3)
Table 3-24: State information (8-bit value)
Value
Description
0
undefined
1
RUN
The FB ESTOP module assumes the RUN state if no error is present and no active EStopIn
input requests a safe state.
The outputs assume the following values:
Error=0
EStopOut=1
EStopDelOut=1
2
STOP
The FB ESTOP module assumes the STOP state if the input FbRun is FALSE.
The outputs assume the following values:
Error=0
EStopOut=0
EStopDelOut=0
3
SAFE
The FB ESTOP module assumes the SAFE state as long as at least one of the active
EStopIn inputs has requested the safe state.
The outputs assume the following values:
Error=0
EStopOut=0
EStopDelOut=0
4
ERROR
If the FB ESTOP module detects an error, the FB ESTOP module assumes the ERROR state
and transmits the corresponding Diag message to the GROUP module.
The outputs assume the following values:
Error=1
EStopOut=0
EStopDelOut=0
