Beckhoff TwinSAFE logic FB User Manual

Function blocks
60 Function blocks for TwinSAFE logic components
Value
Description
7
ERRORDELAY
The FB MON module assumes the ERRDELAY state if a discrepancy error occurs in
the RUN state (DiscError=TRUE) and the delay time for the MonDelOut output has
not yet expired. This state can only be assumed if the output delay time in the
configuration data is not 0.
The outputs assume the following values:
Error=0
MonOut=0
MonDelOut=1
8
DELAYOUT
The FB MON module assumes the DELAYOUT state if at least one of the active
MonIn inputs and at least one of the active Secure inputs has requested the safe
state and the delay time for the MonDelOut output has not yet expired. This state can
only be assumed if the output delay time in the configuration data is not 0.
The outputs assume the following values:
Error=0
MonOut=0
MonDelOut=1
9
FUNCTEST
The FB MON module assumes the FUNCTEST state if the manual function test is
enabled in order to test all active MonIn inputs once after startup. This state can only
be assumed if the manual function test is enabled in the configuration data.
The outputs assume the following values:
Error=0
MonOut=0
MonDelOut=0
If the checkboxes 'Map State' and 'Map Diag' are checked, the state and diagnostic data of the FB are
copied to the cyclic process image.
NOTE
KL6904
The checkboxes 'Map State', 'Map Diag' and 'Safe Inputs after Discrepancy Error' are not available in the
KL6904.
