Function blocks
Function blocks for TwinSAFE logic components 69
3.6.2.1 Diagnostic and state information for FB DECOUPLE
Table 3-35: Diagnostic information (16-bit value)
Bit
Description
0
always 0
Table 3-36: State information (8-bit value)
Value
Description
0
undefined
1
RUN
The FB DECOUPLE module assumes the RUN state if the input FbRun is
TRUE.
The outputs assume the following values:
DcOutX=DcInX
2
STOP
The FB DECOUPLE module assumes the STOP state if the input FbRun is
FALSE.
The outputs assume the following values:
DcOutX=0
If the checkboxes 'Map State' and 'Map Diag' are checked, the state and diagnostic data of the FB are
copied to the cyclic process image.
NOTE
KL6904
The checkboxes 'Map State' and 'Map Diag' are not available for the KL6904.
