Beckhoff TwinSAFE logic FB User Manual

Function blocks
82 Function blocks for TwinSAFE logic components
Value
Description
5
RESET
The FB MUTING module assumes the RESET state if no further error is pending after an
error has occurred and the ErrAck input of the corresponding group is set to TRUE.
The outputs assume the following values:
Error=0
MutingActive=0
MuteOut=0
MuteDelOut=0
6
not used
7
not used
8
DELAYOUT
The FB MUTING module assumes the DELAYOUT state if OssdInActive is FALSE and
MutingEnable is FALSE and the delay time for the MuteDelOut output has not yet expired. If
a discrepancy error occurs in the DELAYOUT state, the FB MUTING module does not
assume the ERROR state until the output delay time has elapsed.
The outputs assume the following values:
Error=0
MutingActive=0
MuteOut=0
MuteDelOut=1
9
MUTING1 (Figure 3-35 number 2-3)
The outputs assume the following values:
Error=0
MutingActive=1
MuteOut=1
MuteDelOut=1
10
MUTING2 (Figure 3-35 number 3-4)
Outputs see state 9
11
MUTING3 (Figure 3-35 number 4-5)
Outputs see state 9
12
MUTING4 (Figure 3-35 number 5-6)
Outputs see state 9
13
MUTING5 (Figure 3-35 number 6-7)
Outputs see state 9
14
MUTING6 (Figure 3-35 number 7-8)
Outputs see state 9
15
MUTING7 (Figure 3-35 number 8-9)
Outputs see state 9
16
MUTING8 (Figure 3-35 number 9-10)
Outputs see state 9
17
MUTING9 (Figure 3-35 number 10-11)
Outputs see state 9
