Beckhoff TwinSAFE logic FB User Manual

Function blocks
94 Function blocks for TwinSAFE logic components
Table 3-56: State information (8-bit value)
Value
Description
0
undefined
2
STOP
The FB EDM module assumes the STOP state if the input FbRun is FALSE.
The outputs assume the following values:
Error=0
4
ERROR
If the FB EDM module detects an error, the FB EDM module assumes the ERROR state and
transmits the corresponding Diag message to the GROUP module.
The outputs assume the following values:
Error=1
5
RESET
The FB EDM module assumes the RESET state if no further error is pending after an error
has occurred and the ErrAck input of the corresponding group is set to TRUE.
The outputs assume the following values:
Error=0
14
MON_OFF
If the input MonIn1 is FALSE, the FB EDM module assumes the MONOFF state in order to
perform switch-off monitoring.
The outputs assume the following values:
Error=0
15
MON_ON
If the input MonIn1 is TRUE, the FB EDM module assumes the MONON state in order to
perform switch-on monitoring.
The outputs assume the following values:
Error=0
