GB Sound speed controller SFR-1
06.02.2019 BEIER-Electronic 39
Output „Combined headlight“
Using the combined headlight, “parking light“, “low beam headlight“ and “high
beam headlight“ can be switched using just one output.
The Intensity for each of the 3 lights can be adjusted seperately:
The intensity of the parking light is entered under “intensity“(e.g. 10%).
The intensity of the low beam headlight is entered under “Option 1“(e.g. 30%).
The intensity of the high beam headlight is entered under “Option 2“(z.B. 60%).
However, it should be noted that these 3 intensities are added, if more than one light
is switched on. Summing up, you should avoid a value that is over 100%.
Output “Combined back light“
Using the combined rearlight, “parking light“, “brake light“ and “rear fog light“
can be switched using just one output.
The Intensity for each of the three lights can be adjusted seperately:
The intensity of the parking light is entered under “Intensity“(e.g. 10%).
The intensity of the brake light is entered under “Option 1“(e.g. 30%).
The intensity of the rear fog light is entered under “Option 2“(z.B. 60%).
However, it should be noted that these three intensities are added, if more than one
light is switched on. Summing up, you should avoid a value that is over 100%.
Output „Combined American rear light left/right“
This setting switches three light functions, namely „parking light“, “brake light” and
“indicator right” respectively “indicator left” via only one output.
For each of this light functions you can set the intensity separately.
The intensity for “Parking light” is set at “Intensity” for example 10%.
The intensity for “Brake light” is set at “Option 1” for example 100%.
The intensity for “Indicator light” is set at “Option 2” for example 50%.
In contrast to other combined lights, the intensities are not summarised!
Output „Locomotive – driving light forward/backward“
These two output types are triggered via the function "Locomotive - Driving light”. If
the locomotive is moving forwards, the output "Locomotive - Driving light forward" is
activated. If the locomotive runs backwards, the output "Locomotive - Driving light
backward" is activated. In stand always the last switched output remains switched
on.
Output “In motion on“
This output is always switched on when the model is in motion, whether it is moving
forwards or in reverse.
Output “In stationary on“
This output is always switched on when the model is stationary.
