GB Sound speed controller SFR-1
40 BEIER-Electronic 06.02.2019
Output „Stationary/Motion“
With this function the output is always active, regardless of whether the model is
moving or not. The value “Intensity” defines the light intensity during standing.
“Option 1” defines the intensity when the model is in motion (0-100%). The change
between both light intensities is executed smoothly.
Output “At accelerating on“
This output is always switched on briefly as soon as the model accelerates from
standing.
Output “At driving speed on“
This output is switched on when the model exceeds a defined running speed level.
This level is entered under “Option 1“.
Output "Smoke generator - heater“ and „Smoke generator - fan“
These output types are for connecting a proportional smoke generator. Depending
on the state (engine start, idle, accelerating and running speed) of the model, the
output is controlled with varying intensity. Thus, smoke emissions (per fan) are
produced to suit the particular situation.
With the output type “fan” a trailing can be set (see page 40).
The smoke emissions can be adjusted using the 3 parameters "Brightness", "Option
1" and "Option 2":
• At "Brightness" the intensity of the smoke emissions during engine start and
acceleration can be set (e.g. 100%).
• At "Option 1" the intensity of the smoke emissions while standing (e.g. 20%)
can be adjusted.
• At "Option 2" the maximum smoke intensity at full running speed (e.g. 90%)
can be defined. The corresponding smoke intensity at each speed level
between start and full running speed is calculated automatically.
The output is activated via the the function "Smoke generator on" or automatically
when turning on the driving sound (see page 70).
Outputs for military vehicles: „black out headlamp“, „disguise rear light“,
„disguise brake light“ und „guidance cross“
These outputs can only be switches with the programmable light switch (see page
72) using the functions "light switch +" and "light switch -".
Output „Temperature controlled“
If the motor output stage requires some cooling with an additional fan, the fan can be
controlled via the existing temperature sensor. In Configuration  Outputs 
Outputs you can define from which temperature the fan should be switched on
("Option 2") and at which temperature the fan should be switched off again ("Option
1").
