BEKA FKGGM-EP - Technical Data and Functional Description; General Technical Data

2. Technical data FKGGM-EP / EPR
GENERAL:
Reservoir capacity:
Central lubrication pump FKGGM - EP: .....................................................1,9 l / 2,5 l / 4 l / 8 l / 12 l / 16 l / 20 l / 30 l
Central lubrication pump FKGGM - EPR:............................................................................ 4 l / 8 l / 12 l / 15 l / 20 l
Medium:..............................................................................................greases up to consistency class NLGI-cl. 2
Operating temp. range: ..........................-25°C to +60°C (depends on lubricant, up to -40°C possible on demand)
Transport and storage temperature:.............................................................................................- 40°C to + 70°C
Sound pressure level: .............................................................................................................................<70db(A
Level monitoring (optional): ...................................................................................................Min. / Max. / reserve
Installation position:
Central lubrication pump FKGGM - EP: ...................................................................................................vertical
Central lubrication pump FKGGM - EPR: ....................................................................................rotating system
PUMP:
Operating voltage for version DC: .......................................................................................................12/24 V DC
Operating voltage for version AC ( : .......................................................................... 100-250 VAC
via installed PSU)
Current consumption max.......................................................................................................4A(5 A, t < 100 ms)
Fuse: ...................................................................................................................................... 5Adelay (DC)
KFZ
................................................................................................................... 6Aautomatic fuse C (AC/DC)Industry
.................................................................................................................................. 6,3Adelay (AC/DC)Industry
Protection class: ...........................................................................................................................................IP 65
Number of outlets: ..........................................................................................................................................1 - 3
Pipe connection:..............................................................................................................................ø 6 / ø 8 / ø 10
Delivery rate:
Pump element PE-60 .................................................................................................................0,06 cm / stroke
3
Pump element PE-120 ...............................................................................................................0,12 cm / stroke
3
Pump element PE-120 V ............................................0,12 cm / stroke can be regulated back to 0,05 cm³ / stroke
3
Pump element PE-170...............................................................................................................0,17 cm³ / stroke
max. operating pressure: ..........................................................................................................................350 bar
Pressure limiting valve set to:........................................................................................................280 bar (+15%)
Sense of rotation of agitator blade (FKGGM - EP / EPR) ............................................................counter clockwise
MOTOR:
Drive: ...............................................................................................................................D/C motor 12/24 V DC
Power input: ....................................................................................................................................< 100 W (DC)
.......................................................................................................................................................< 130 VA(AC)
Pump speed:...................................................................................................................................15 turns / min.
CONTROL UNIT:
Operating voltage:.............................................................................................................................10 - 60 V DC
MATERIAL:
Lubrication reservoir: ........................................................................................... plastic,transparent / aluminium
Pump housing:..............................................................................................................................aluminium cast
Motor cover / control unit housing:...............................................................................................................plastic
Pump parts: ..................................................................................................................................steel C4 / 720 h
acc. to BEKAcompany standard corrosivity categoryA............................................................................zinc-nickel coated acc. to DIN 50979
Missing details and technical data can be found on the data sheets and operating manuals of the
manufacturers (on request).
Please always observe this documentation for all works with the central lubrication system!
10
Attention!
Subject to alterations!
