4.3 Central lubrication pump FKGGM - EP with installed MX-F distributor
Fig. 31:
172
250
130
ø152
107
224
342
133
5 x grease outlet ø6
33
Subject to alterations!
...a product from
BAL2076_central lubrication pump_0119EN
© BEKA 2019 All rights reserved
