BEKA FKGGM-EP - FKGGM-EPR Installation Dimensions

4.2 Central lubrication pump FKGGM - EPR
4.2.1 Central lubrication pump EPR
4 liter reservoir
Fig. 26:
4.2.2 Central lubrication pump EPR
8 liter reservoir
Fig. 27:
130
ø9,5
172
342
117
236
ø232
ø6
442
132
40
ø6
172
342
230
ø11
142
261
ø232
537
40
124
29
Subject to alterations!
