15. Accessories
15.1 Protective housing
Protective housings can be used to protect the device. Those are available in different versions (fig. 16 + 17). The integrated bores
enable the filling of the device via zerks and the control of the inspection windows. The adjusting throttle can also still be reached to
regulate the flow rate.
Fig. 16:
(only for version M14)
Article no.:
Protective housing incl. fastening material: 10104301
Protective housing without fastening material: 10104212
Fig. 17:
(for version M14 and M16)
Article no.:
Protective housing without fastening material: 10102722 ød=15,5 (version M14)
Protective housing without fastening material: 0800802261 ød= 17 (version M16)
Fastening material: Hexagon bolt M12x20 10124601
Washer B13 10100959
Spring lock washer A12 10134844
