Chapter 1 General Machine Operation
Typical Wash Structure
Entrance Features
The system is equipped with three entrance features that the vehicle receives from the time the wash package is
selected until soon after the vehicle arrives at the Wash Position. The configuration of these functions is very
dynamic. Refer to the chapter setup / entrance operation of this manual to check if these functions can
accommodate your special needs. Some examples of the types of equipment controlled by these features/functions
are as follows: CTA, undercarriage, titan, rocker blaster, soap arch, bug manifold, etc. Check if equipment to meet
your needs is available.
Wash
The wash begins at the exit of the bay when the vehicle pulls Into the Wash Position. Each motion from (front to
back) and (back to front) is considered one pass. The machine moves back and forth over the full length of the
vehicle in pass order determined by the package. The pass order of each package may be changed. When there are
not any more passes, the machine will instruct the driver to pull forward. If the machine is not at the exit when the
wash is done it will move rapidly to the Home Position.
Exit Features
The system is equipped with three exit features. These are features that the vehicle receives as it is pulling out of
the bay after wash is complete. The configuration of these functions is very dynamic. Refer to the chapter setup /
exit operation of this manual to check if these functions can accommodate your special needs. Some examples of
the types of equipment controlled by these features/functions are as follows: Dryer, Wax Arch, Spot Free Arch, etc.
Check if equipment to meet your needs is available.
Receive none or up
to 3 Entrance
Features
Wash package
selected
(Wash
Receive wash
to 3 Exit Features
Wash package selected may
be performed in many ways.
Some typical methods are as
follows:
• POS (Point of Sales)
• Push Buttons
• Fleet Loader Photo-Eye
The three entrance features can
be turned on or off with many
combinations of the following:
• Wash Package Selected
• Make or break beam of up to
3 Photo-Eyes
• Max Time
• Treadle
The three exit features can
be turned on or off with
many combinations of the
following:
• Wash End
• Make or break beam
of up to 2 Photo-Eyes
• Any point in wash
• Max Time
• Treadle
Wash can be configured by
selecting pass order of pre-
defined applications such as:
Soap, Rinse, Drying Agent,
Sealer Wax, etc.
The system has 12 different
pre-defined applications.
These applications can be
changed via the E-1032
To Next Page
