BHT-429-MPI
Table1.ConditionalInspections-SuddenStoppage(MainRotor)PowerONorOFF(continued)
INITIAL
DATAREFERENCEINSPECTIONTASKDESCRIPTION
MECHOTHER
c.Visuallyexaminetheswashplateandsupportassemblyforcondition.
Ifthesuddenstoppagecauseddamage,dothefollowing:
(1)Removeanddiscardallthecontrolboltsfromthehydraulicservo
actuatorstothegripassemblies.
(2)Removetheswashplateandsupportassembly.
(3)AttachaTHISCOMPONENTWASREMOVEDFROMSERVICE
BECAUSEOFASUDDENSTOPPAGEtagontheswashplateand
supportassembly.
(4)Disassemble,clean,anddoadetailedinspectionoftheswashplate
andsupportassembly.
d.Ifnoneoftheabovedamageisfound,theswashplateandsupport
assemblyisserviceable.
429-MM,Chapter63MAINROTORDRIVESYSTEM
1.Doadetailedinspectionofthemastassemblyasfollows:
NOTE
Ifthemastassemblywasbrokenintwoduringasuddenstoppage
(mainrotor)powerON,themastassemblyhassustainedtorsional
yielding.
429-MM,Chapter63
a.Sendthemastassemblytoanapprovedrepairfacilitytodoacheck
oftheTotalIndicatedRunout(TIR)toexaminethemastassemblyfor
torsionalyielding.
NOTE
RefertoGeneralInformationLetter(IL)GEN-04-98fortheappli-
cableshippinginformationandtoobtainaReturnMaterialAutho-
rization(RMA)number.
b.IfthemastassemblyisoutsidetheTIRlimits,sendthemastassembly
toBellforconrmationofthetorsionalyielding.Uponconrmation,do
thefollowing:
(1)Discardthemastassembly.
(2)Discardtheengine-to-transmissiondriveshafts.
(3)Removethetransmissionassembly,verticalLiquidInertialVibration
Eliminator(LIVE)mounts,andpitchrestraintspringassemblies.
(4)AttachaTHISCOMPONENTWASREMOVEDFROMSERVICE
BECAUSEOFASUDDENSTOPPAGEtagonthetransmission
assembly,verticalLIVEmounts,andpitchrestraintspringassemblies.
429-MM,Chapter63
(5)Sendthetransmissionassemblytoanapprovedrepairfacilityto
disassemble,clean,anddoadetailedinspection.
(6)CleananddoadetailedinspectionoftheverticalLIVEmounts.
(7)Cleananddoadetailedinspectionofthepitchrestraintspring
assemblies.
c.Ifthereisdamagetothemastassemblyotherthantorsionalyielding,
dothefollowing:
(1)Discardthemastassembly.
(2)Removethetransmissionassembly.
(3)AttachaTHISCOMPONENTWASREMOVEDFROMSERVICE
BECAUSEOFASUDDENSTOPPAGEtagonthetransmission
assembly.
Applicableto:ALL429-A-05-50-00-01A-284A-A
ECCNEAR99
10JAN2019-Issue1Page3
