BHT-429-MPI
Table1.ConditionalInspections-LightningStrike(continued)
INITIAL
DATAREFERENCEINSPECTIONTASKDESCRIPTION
MECHOTHER
TAILROTORCONTROLS
1.Doaninspectionofthetailrotorcontrolsasfollows:
a.Visuallyexamineeachpitchlinkassemblyforcondition.Ifsignsof
arcingarevisible,discardthepitchlink.
b.Visuallyexaminethecrossheadandthepitchchangecontroltubeof
thepitchchangemechanism.Ifthelightningstrikecauseddamage,
dothefollowing:
c.Removethepitchchangemechanism.
d.AttachaTHISCOMPONENTWASREMOVEDFROMSERVICE
BECAUSEOFALIGHTNINGSTRIKEtagonthepitchchange
mechanism.
e.Disassemble,clean,anddoadetailedinspectionofthepitchchange
mechanism.
429-MM,Chapter64
429-MM,Chapter67
f.Ifsignsofarcingorburningarevisibleonapart,discardthepart.
429-MM,Chapter65TAILROTORDRIVESYSTEM
1.Doaninspectionofthetailrotordriveshaftassemblyasfollows:
a.Removeanddisassemble,asapplicable,allthecomponentsofthe
tailrotordriveshaftassembly.
b.Visuallyexamineallthecomponentsofthetailrotordriveshaftsfor
signsofarcburns.Ifarcburnsarefoundonanyonecomponent,do
thefollowing:
(1)Discardthesegmentedshaftassembliesandthefanshaftassembly
(exceptforthetwoblowerimpellersandblowerhousings).
(2)Replacealltheballbearingsbeforeyoureturnthetailrotordriveshaft
assemblytoservice.
c.Visuallyexaminetheforwardandaftimpellersofthefanshaft
assemblyforcondition.Ifsignsofarcburnsarevisibleonanimpeller,
discardtheimpeller.
d.Visuallyexaminetheforwarddriveshaftassemblyandbothcoupling
assembliesforcondition.Ifsignsofarcburnsarevisibleonacomponent,
discardthecomponent.
2.Ifnoarcburnsarevisibleonthetailrotordriveshaftassemblyandif
noarcburnsarefoundonthetailrotorhubandbladeassembliesoron
anypartsofthepitchchangemechanism,thenthetailrotorgearbox
isserviceable.
3.Ifarcburnsarevisibleonthetailrotordriveshaftassemblyorifarc
burnsarefoundonthetailrotorhubandbladeassembliesoronany
partsofthepitchchangemechanism,dothefollowing:
a.Removethetailrotorgearbox.
b.AttachaTHISCOMPONENTWASREMOVEDFROMSERVICE
BECAUSEOFALIGHTNINGSTRIKEtagonthetailrotorgearbox.
429-MM,Chapter65
c.Sendthetailrotorgearboxtoanapprovedrepairfacilityto
disassemble,clean,anddoadetailedinspection.
d.Replacealltherollerbearingsandballbearingsbeforeyoureturn
thetailrotorgearboxtoservice.
4.Ifthetailrotorgearboxisserviceable,visuallyexaminethechip
detectorforcontaminationafter5to10hoursofoperation.Ifthereare
unwantedparticles,dothefollowing:
a.Removethetailrotorgearbox.
Applicableto:ALL429-A-05-50-00-08A-284A-A
ECCNEAR99
10JAN2019-Issue1Page5
