Bematech MP-4000 TH - AC Adapter; Communication Cable; Female RJ-45 Connector (Printer)

18
Female RJ-45 Connector (Printer)
Pin Signal
1 TD+
2 TD-
3 RD+
4 TCT
5 RCT
6 RD-
7 NC
8 GND
Communication Cable
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Mal
e
RJ-4
5
Male
RJ-45
AC Adapter
Basic Features
• Universal Input Voltage 90 to 264VAC
• Power Saving < 0.75W (no load standby)
• Consumption: 60W
• Output Voltage: 24V
• Output Current: 2.5A (typical)
• High Efficiency 80% typical
• High Reliability
• Low Ripple & Noise
• Short Circuit Protection
• Overvoltage Protection
• Limited Power Source
Environmental
• Operating Temperature: 0 ~ +40C
• Operating Humidity: 20 ~ 85%
• Storage Temperature: - 40 ~ +70C
• Storage Humidity: 10 ~ 95%
• Hi-Pot:
1500 VAC 1Sec. (P. to S.) for Class I
3000 VAC 1Sec. (P. to S.) for Class II
• MTBF > 50.000Hrs at 25 C
Dimensions
• L110*W62.2*H32mm
