Connectors
Connector Type Description
CN1 RJ12 CONNECTOR Cash drawer connector
CN2 A-1009 CONNECTOR Power Supply connector
CN3 90° 2x4 pin bar
Cash drawer configuration
Position: 1-2 and 5-6 – Epson Standard Drawer
Position: 3-4 and 7-8 – Bematech Standard
Drawer
CN4
JST B2B-PH-KS
CONNECTOR
ON/OFF switch connector
CN5
PHEC40R-R211LF 40 PIN
CONNECTOR
Interface board connector
CN6 Vertical 1x5 pin bar Reserved.
CN7 Vertical 2x5 pin bar Reserved.
CN8
PHEC40R-R211LF 40 PIN
CONNECTOR
Printing module connector
Jumpers
Connector Type Description
JPF1 1x2 pin bar
When closed allows the entire board to be supplied
by 24V. This jumper must be closed for the printer
to work.
JPF2 1x2 pin bar
When closed interconnects the logic GND to the
power GND. This jumper must be closed for the
printer to work.
JPF3 1x2 pin bar
When closed allows the entire board to be supplied
by 5V. This jumper must be closed for the printer
to work.
JPF4 1x2 pin bar
When closed allows the board to be supplied by a
voltage of 3.3V. This jumper must be closed for
the printer to work.
JP1 Wire jumper Reserved. (keep jumper open)
JP2 Wire jumper Reserved. (keep jumper open)
JP3 Wire jumper Reserved. (keep jumper open)
JP4 Wire jumper Reserved. (keep jumper closed)
JP5 1x2 pin bar
When closed disables the cutter operation. This
jumper must be open for the proper cutter
operation.
JP6 1x2 pin bar Reserved. (keep jumper open)
JP7 1x2 pin bar Reserved. (keep jumper open)
