BENDIX TABS-6 User Manual

13
22. DIAGNOSTIC TROUBLE CODES (DTCS)
1st
Digit
2nd
Digit
Diagnostic Code
Description
Possible Causes / Repair Information
J1587
(SID/
FMI)
J1939
(SPN/
FMI)
1 1 Nodiagnosticcodes
• The Bendix
®
TABS‑6
™
Adv MC module system is fully operational –
no diagnostic codes are detected.
000/00 000/00
WheelSpeedSensors(WSS);“S-C”,“S-D”,“S-E”,“S-F”
2 1
LargeAirGap:
Sensor “S‑C”
DynamicWheelSpeedSensorDTC-largeairgapbetweensensor
and tone ring.
GotoSectionEonPage38.
001/00 789/00
3 1
LargeAirGap:
Sensor“S-D”
002/00 790/00
4 1
LargeAirGap:
Sensor“S-E”
003/00 791/00
5 1
LargeAirGap:
Sensor “S‑F”
004/00 792/00
2 2
Shorted or open
wire:
Sensor “S‑C”
StaticWheelSpeedSensorDTC-shortedoropensensorwire.
GotoSectionEonPage38.
001/03
001/04
789/03
789/04
3 2
Shorted or open
wire:
Sensor“S-D”
002/03
002/04
790/03
790/04
4 2
Shorted or open
wire:
Sensor“S-E”
003/03
003/04
791/03
791/04
5 2
Shorted or open
wire:
Sensor “S‑F”
004/03
004/04
792/03
792/04
2 3
DynamicIssue:
Sensor “S‑C”
DynamicWheelSpeedSensorDTC-incorrectwheelspeedsignal
detected while vehicle is in motion.
GotoSectionEonPage38.
001/08
001/01
001/02
789/08
789/01
789/02
3 3
DynamicIssue:
Sensor“S-D”
002/08
002/01
002/02
790/08
790/01
790/02
4 3
DynamicIssue:
Sensor“S-E”
003/08
003/01
003/02
791/08
791/01
791/02
5 3
DynamicIssue:
Sensor “S‑F”
004/08
004/01
004/02
792/08
792/01
792/02
2 4
TireDiameterOutof
Range:
Sensor “S‑C”
• Verify the correct tire size as desired.
•Verifythepropertireination.
• Verify the correct number of exciter/tone ring teeth.
•VerifythattheTABS-6AdvMCmoduleECUhasbeenprogrammed
with the correct tire size and tone ring settings.
001/13 789/13
3 4
TireDiameterOutof
Range:
Sensor“S-D”
002/13 790/13
4 4
TireDiameterOutof
Range:
Sensor“S-E”
003/13 791/13
5 4
TireDiameterOutof
Range:
Sensor “S‑F”
004/13 792/13

BENDIX TABS-6 Specifications

General

Type	Trailer ABS Module
Operating Temperature Range	-40°C to +85°C
Protection Rating	IP67
Category	Automobile Accessories
Voltage	12V/24V
Communication	J1587/J1939
Mounting	Frame Mount
Manufacturer	BENDIX
System Type	ABS
Number of Channels	4S/2M
