7
deection.Theconnection tothe ElectronicControl
Unit(ECU)isviatheauxiliary12-pinconnector.See
Figure 6.
6. MOUNTING
Frame (Chassis) Mount
The Bendix
®
TABS‑6
™
Adv MC module provides three
M10,1.18in.(30mm.)studsforframemountingdirectly
to a trailer cross‑member. The TABS‑6 Adv MC module
usesthreeClass8steelM10x1.5nutswithlockwashers,
torquedto354±44.4in.-lbs(40±5Nm).Abracketmaybe
used if direct mounting to a cross‑member is not possible.
7. PIGTAIL WIRING HARNESSES
Several pigtail wire harnesses are available to connect
the TABS‑6 Adv MC module with other trailer system
components. See Figure 6. Pigtail harnesses are weather‑
sealed at the connector interface and are clearly labeled for
proper installation. Because of the over‑molded design of
the wiring harnesses, Bendix recommends that if damage
or corrosion occurs, the complete harness be replaced.
Wheel Speed Connectors
The TABS‑6 Adv MC module includes two primary and
two secondary wheel speed sensor connections separate
fromthemainvehiclepigtailharnesses,andeachrequires
a separate harness.
ECU Connectors
TheTABS-6AdvMCmoduleECUhastwoconnectors(in
addition to the wheel speed sensor connectors mentioned
above). The primary connector is a 7‑pin custom series
screw‑on type connector used to connect to the vehicle’s
power pigtail harness. The otherconnector is a 12-pin
DeutschDTseriesstyleconnector,usedforauxiliaryinputs
andoutputs(I/Os).
POWER AND GROUND
Trailer electrical power is supplied to the TABS‑6 Adv MC
module from the ignition and brake light circuits.
See Charts 1 and 2 for output values and pin locations.
Function Mode Value
OperatingRange 8.0to32.0VDC
ECUActive 150mA@12VDC
ABS Active 2.0A@12VDC
CHART 1 – VALUES FOR OUTPUTS
Circuit
7‑Pin
Trailer
Conn.
5‑Pin
ABS
Conn.
7‑Pin
ECU
Conn.
IgnitionPowerPLC
(Blue Wire)
7 B 1
BrakeLightPower
(Red Wire)
4 A 2
Ground
(White Wire)
1 E 4
IndicatorLamp
(White/Green Wire)
N/A D 5
CHART 2 – POWER AND GROUND
Power/ABS Indicator Lamp Connector
The TABS‑6 Adv MC module pigtail uses a TTMA RP 97‑99
5‑pin Packard Weather Pack connector for brake light
power, constant power, ground and the trailer‑mounted
ABS indicator lamp.
SAE J1939 (CAN) Connector
See Figure 6.
TABS-6Adv MC module 12-pin auxiliary harnesses
typicallyincludea4-pinconnectorusedforvariousECU
communications.TypicalusesincludeJ1939diagnostics,
and connection to the Bendix
®
Trailer Information Module.
Auxiliary I/O Connector
The TABS-6Adv MC module 12-pin auxiliary harness
providesanoptionforuptothreeauxiliaryI/Os.
Examplesofusesoftheauxiliaryconnectorare:
• Liftaxlesensing.
• Rear axle suspension air bag dump.
• SAEJ1939Diagnostics.
• Automatic lift axle control.
• Externalspringdeectionsensorformechanicalspring
suspensions.

BENDIX TABS-6 Specifications

General

Type	Trailer ABS Module
Operating Temperature Range	-40°C to +85°C
Protection Rating	IP67
Category	Automobile Accessories
Voltage	12V/24V
Communication	J1587/J1939
Mounting	Frame Mount
Manufacturer	BENDIX
System Type	ABS
Number of Channels	4S/2M
