27
FIGURE 22 - BENDIX
®
TABS -6
ADV MC MODULE - 2S/2M SIDE CONTROL (0 DEGREE) ABS ELECTRICAL & AIR SYSTEM
FIGURE 23 - BENDIX TABS-6 ADV MC MODULE - 2S/2M SIDE CONTROL (180 DEGREE) ABS ELECTRICAL & AIR SYSTEM
Troubleshooting: System Schematics
2S/2M - SIDE CONTROL - Fixed Axles
0 Degree Mounting Orientation
Ignition
Power
Trailer Chassis Harness
Bendix
®
TABS-6
Advanced
Multi-Channel
Bendix
®
SR-5
Trailer
Spring Brake
Valve
Trailer ABS Pigtail Harness
ABS Indicator Lamp
5-Pin ABS
Connector
Supply Line
Control Line
Right - “Curb-Side”
Semi-Trailer Tandem Axle Trailer
Left - “Road-Side”
7-Pin SAE J560
Connector
P21
P22
Brake Lamp Power
Ground
“S-D”
“S-C”
Bendix
®
WS-24
Wheel Speed Sensor
Bendix
®
WS-24
Wheel Speed Sensor
Air Bellow
(where used)
Load Sensor
(where used)
A Brake Lamp Power
B Ignition Power
C NC
D Indicator Lamp
E Ground
2S/2M - SIDE CONTROL - Fixed Axles
180 Degree Mounting Orientation
ABS
Ignition
Power
Trailer Chassis Harness
Bendix
®
TABS-6
Advanced
Multi-Channel
Bendix
®
SR-5
Trailer
Spring Brake
Valve
Trailer ABS Pigtail Harness
ABS Indicator Lamp
5-Pin ABS
Connector
Supply Line
Control Line
Right - “Curb-Side”
Semi-Trailer Tandem Axle Trailer
Left - “Road-Side”
7-Pin SAE J560
Connector
Brake Lamp Power
Ground
“S-C”
“S-D”
Bendix
®
WS-24
Wheel Speed Sensor
Bendix
®
WS-24
Wheel Speed Sensor
P21
P22
Air Bellow
(where used)
Load Sensor
(where used)
A Brake Lamp Power
B Ignition Power
C NC
D Indicator Lamp
E Ground
