BENDIX TABS-6 - 4 S;2 M - SIDE CONTROL - Front Lift Axle

31
FIGURE 30 - 4S/2M SIDE CONTROL (180 DEGREE) WITH FRONT LIFT AXLE, ABS ELECTRICAL & AIR SYSTEM
FIGURE 31 - 4S/2M SIDE CONTROL (180 DEGREE) WITH REAR LIFT AXLE, ABS ELECTRICAL & AIR SYSTEM
Troubleshooting: System Schematics
ABS
4S/2M - SIDE CONTROL - Front Lift Axle
180 Degree Mounting Orientation
Ignition
Power
Bendix
®
SR-5
™
Trailer
Spring Brake
Valve
Supply
Line
Control
Line
Left - “Road-Side”
7-Pin
SAE J560
Connector
Bendix
®
WS-24
™
Wheel Speed Sensors
A Brake Lamp Power
B Ignition Power
C NC
D Indicator Lamp
E Ground
Trailer Chassis Harness
Bendix
®
TABS-6
™
Advanced
Multi-
Channel
Trailer ABS Pigtail Harness
Dashed-line box
Shows Lift Axle
ABS Indicator Lamp
Air Bellow
(where used)
Load Sensor
(where used)
5-Pin ABS
Connector
Right - “Curb-Side”
Semi-Trailer Tandem Axle Trailer
P21
P22
Brake Lamp
Power
Ground
“S-D”
“S-C”
Bendix
®
WS-24
™
Wheel Speed Sensors
“S-E”
“S-F”
Lift Axle
Ignition
Power
Bendix
®
SR-5
™
Trailer
Spring Brake
Valve
Dashed-
line box
Shows
Lift Axle
Supply
Line
Control
Line
Left - “Road-Side”
7-Pin
SAE J560
Connector
Bendix
®
WS-24
™
Wheel Speed Sensors
Lift Axle
4S/2M - SIDE CONTROL - Rear Lift Axle
180 Degree Mounting Orientation
A Brake Lamp Power
B Ignition Power
C NC
D Indicator Lamp
E Ground
Trailer Chassis Harness
Bendix
®
TABS-6
™
Advanced
Multi-
Channel
Trailer ABS Pigtail Harness
ABS Indicator Lamp
Air Bellow
(where used)
Load Sensor
(where used)
5-Pin ABS
Connector
Right - “Curb-Side”
Semi-Trailer Tandem Axle Trailer
P21
P22
Brake Lamp
Power
Ground
“S-D”
“S-C”
Bendix
®
WS-24
™
Wheel Speed Sensors
“S-E”
“S-F”
