BENDIX TABS-6 User Manual

19
1st
Digit
2nd
Digit
Diagnostic Code
Description
Possible Causes / Repair Information
J1587
(SID/
FMI)
J1939
(SPN/
FMI)
11 8
AuxiliaryElectrical
Error#4
• Clear diagnostic codes.
• If the diagnostic code persists, contact your local Bendix
representative before replacing the TABS‑6 Adv MC module.
152/12 612/12
11 9
Auxiliary Program
Error–ADL
•VerifythattheAuxiliaryI/OECUpin-outsmatchtheADLparameters
using the Bendix
®
ACom
®
diagnosticsoftware(version6.1orhigher).
• If necessary, contact your local Bendix representative to troubleshoot
theADLprogram.
152/12 612/12
11 10
LowSupply
Pressure
• Check if the trailer’s service reservoir pressure is < 75 psi
(5.2 bar).
• If the trailer’s service reservoir pressure is > 75 psi (5.2 bar):
CycleIgnitionpower“OFF”and“ON”.
• If the diagnostic code persists, contact your local Bendix
representative before replacing the Bendix
®
TABS‑6
™
Adv MC
module.
152/01 612/01
11 11
WL(IndicatorLamp)
Information–ADL
•VerifythattheADLparametersarecorrectusingtheBendix
®
ACom
®
diagnosticsoftware(version6.1orhigher).
• If necessary, contact your local Bendix representative to troubleshoot
theADLprogram.
152/14 612/14
Miscellaneous
12 1
ServiceDistanceor
DateExceeded
• Perform scheduled trailer maintenance and/or reset the Service
DistanceorDate.
• Perform the Installation Test using the Bendix ACom diagnostic
software(version6.1orhigher),orBendix
®
Trailer Information
Module.
153/00 612/00
12 2
TrailerLoadOutof
Range
•Iftrailerisequippedwitharaise/lowervalve,verifyitisinthedrive
position.
•VerifythattheECUparametersfortheemptyandfullyloadedtrailer
conditions are correct using the Bendix ACom diagnostic software
(version6.1orhigher),orBendixTrailerInformationModule.
• If necessary, contact your local Bendix representative to troubleshoot
the trailer’s loading condition.
069/13 1059/13
12 3 Brake Pads Worn
• Manually check the condition of the pads on each brake to determine
ifanyrequirereplacement.
•Ifnopadsrequirereplacement,checkthewearsensorsandcables
for damage or defects.
070/01 1060/01
12 4
LowSystem
Pressure,P1
• Check if the trailer’s service reservoir pressure is < 65 psi
(4.5 bar).
• If the trailer’s service reservoir pressure is > 65 psi (4.5 bar):
CycleIgnitionpower“OFF”and“ON”.
• If the diagnostic code persists, contact your local Bendix
representative before replacing the TABS‑6 Adv MC module.
254/11 1086/11
12 8
Trailer Information
Module Missing
• Trailer Information Module and/or harness damaged or not present. 254/11 0/11
MechanicalLoadSensor
13 4 LoadSensorError
• (Spring Suspension Systems) Inspect the linkage: Check that the
linkage is attached to the axle, inspect for damage to the linkage
components, loose connectors and mis‑installation.
• If the diagnostic code persists, contact your local Bendix
representative before replacing the TABS‑6 Adv MC module.
69/13 0/13
Diagnostic Trouble Codes (DTCs) (continued)

BENDIX TABS-6 Specifications

General

Type	Trailer ABS Module
Operating Temperature Range	-40°C to +85°C
Protection Rating	IP67
Category	Automobile Accessories
Voltage	12V/24V
Communication	J1587/J1939
Mounting	Frame Mount
Manufacturer	BENDIX
System Type	ABS
Number of Channels	4S/2M
