OPTIONAL EQUIPMENT INSTALLATION
34
HDS/HDSO-14LSX Rolling Jack Air Line Kit Installation
Part # 5174009
REV 03/21/2012
5174009 HD-9/12/14, HDS/HDSO-14LSX/LSXE
AIR LINE KIT
PART # Description Qty.
5550502 1/4 Bulkhead Female Straight 3/8 Tube 3
5550503 3/8 Tube Male Elbow 90° 1/4 NPT 3
5550504 1/4 Male Run Tee 3/8 Tube #PST 1
5570784 Ø3/8 x 10ft Long Poly Tube Coil Hose 2
5570725 Ø10mm Poly Flow Tube 260”
Rolling Jack maximum weight capacity for use with
HDSO-14P or HDSO-14AX is 7,000 lb (3,175 kg) per unit.
