BendPak HD-7W - Introduction and Product Overview; Critical Safety Warnings for Lift Operation

2537.0mm
99.882in
2218.0mm
87.323in
121.0mm
4.764in
4.090in
103.9mm
3.268in MAX
83.0mm MAX
63.371in
1609.6mm
A
B
4178.0mm
164.488in
2546.0mm
100.236in
887.0 MIN 1045.0mm MAX
[34.921 MIN - 41.142in MAX]
482.0mm
18.976in
173.937in
4418.0mm
200.407in
5090.3mm
9.016in
229.0mm
111.870in
2841.5mm
80.906in
2055.0mm
DRIVE THRU
FRONT VIEW
4.010in
101.9mm
DETAIL A
SCALE 1 : 10
4.264in
108.3mm
DETAIL B
SCALE 1 : 10
SHEET 2 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
AE
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260515
HD-7W PRODUCTION
LIFT VER D (CE CERT)
1:35
SCALE:
