9. Check all MAIN SAFETY LOCKS to make sure
they move freely and spring back to the lock position
when released. Lubricate all SAFETY PIVOT points with
WD-40 or equal.
10. Run the lift up and down a few times to ensure that
the locks are engaging uniformly and that the safety
release mechanisms are functioning. Re-adjust if neces-
sary.
STEP 14
(Optional - Anchoring the Posts)
1. Before proceeding, make certain the lift is positioned
with proper clearances around and overhead. (See Fig 14.1)
2. Using the base of the frame as a guide, drill each
anchor hole in the concrete approximately 4” deep using
a rotary hammer drill and 3/4” concrete drill-bit.
(See Fig 14.2)
3. After drilling the anchor holes, remove the dust thor-
oughly from each hole using compressed air and/or wire
brush. (See Fig 14.3)
4. Assemble the washers and nuts on the anchors then
tap into each hole with a hammer until the washer rests
against the base. Be sure that enough threads are left
exposed, if shimming is required. (See Fig. 14.4)
5. If shimming is required, insert the shims as necessary
around each anchor bolt. (See Fig. 14.5)
Fig. 14.1
Fig. 14.3
CAUTION!
SAFETY GLASSES SHOULD ALWAYS BE WORN
WHEN DRILLING INTO CONCRETE. FAILURE
TO WEAR SAFETY GLASSES COULD RESULT IN
PERSONAL INJURY.
Fig 14.2
Fig 14.4
IMPORTANT NOTE:
BendPak lifts are supplied with installation
instructions and concrete fasteners meeting the
criteria as prescribed by the American National
Standard "Automotive Lifts - Safety Requirements for
Construction, Testing, and Validation" ANSI/ALI
ALCTV-2011. Lift buyers are responsible for any
special regional structural and/or seismic anchoring
requirements specied by any other agencies and/or
codes such as the Uniform Building Code (UBC)
and/or International Building Code (IBC).
Fig 14.5
