8
When removing the lift from shipping angles, pay close attention as the ramps can slide and can cause injury.
Prior to removing the bolts make sure the ramps are held securely by a fork lift or some other heavy lifting device.
PARTS INVENTORY
Be sure to take a complete inventory of parts prior to beginning installation.
Description Qty
Small Window Crosstube 1
Large Window Crosstube 1
Power Post 1
Post 3
Off Side Ramp Assembly 1
Power Side Ramp Assembly 1
Drive-Up Ramps 2
Alignment Turnplate 2
Power Unit 1
Parts Box (Packing List Enclosed) 1
Parts Bag (Packaged in Part Box) 1
Power Post
Drive-Up
Ramp
Off Side Ramp
Assembly
Power Side
Ramp Assembly
Alignment
Turnplates
Post
Small Window
Crosstube
Large Window
Crosstube
