15
EN
INSTRUMENTS
Total/partial kilometre counter
The total kilometre counter shows the
total distance covered in kilometres,.
The partial kilometre counter (TRIP)
shows the distance covered since the
last reset in kilometres.
The partial kilometre counter can be
used to estimate the possible distance
to cover with a full tank of fuel.
This information may make it possible to
schedule future fuelling stops.
RESET/SELECT buttons
Buttons to set vehicle data.
Press the “SELECT” button to see the
partial or total kilometres.
When viewing partial kilometres (TRIP),
it is possible to reset them by holding
down the ”RESET” button for 3 seconds.
Spia diagnosi ABS
1. ABS failure: If any type of ABS failure
is detected and stored, ABS indicator
light is lit and stays on after repaired,
then ABS indicator light will be unlit after
the next Power switch ON/OFF and
when vehicle speed exceeds 5km/h.
2. ABS is under OFF mode: ABS
indicator light Blink 1 time/1.27s(Slow
Blink)
3. When press the the ABS switch within
3s ~30s --ABS indicator light Blink 1
time/0.32s(Quick Blink)
4. ABS is under ON mode: When
keyswitch turned on, the ABS indicator
lamp lit and stays activated, until the
motorcycle drive off,
reaching about 3~5KM/H will the ABS
indicator lamp be unlit.
Normally the ABS indicator light
comes on when the ignition switch is
turned on and goes off shortly after
the vehicle starts moving. If the indi-
cator light shows any of the
following, a fault or faults may have
occurred in the ABS. You should
have the vehicle checked by an
authorized Benelli dealer.
• The light does not come on when the
ignition switch is turned on.
• The light remains lit after the vehicle
moving over 5km/h.
Remember that the ABS does not
function when the indicator light is on,
but if only the ABS system fails (without
any other malfunctions in mechanical
parts, for example, brake hoses, master
cylinders, brake calipers), the conventio-
nal brake system should still work normal-
ly.
WARNING:
