78
EN
DESCRIPTION OF INSTRUMENTS
Injection diagnostic light "FI"
INSTRUMENTS
WARNING:
WARNING:
Senza titolo-2 15 21/12/2015 15:49:49
When the switch is on and the vehicle is
not running, the light will switch on red,
to show that the injection system is ope-
rated correctly, when the vehicle is star-
ted the light is switch off.
If the light begins to flash while the
vehicle is being started, contact your
nearest Benelli assistance centre to
avoid damaging the engine.
High beam indicator light
A blue light switches on when the high
beam is on.
Neutral gear indicator light
A green light that switches on to show
that the gear pedal is in neutral.
Position indicator light
Green and flashing to show the use of
the left and right position indicators.
Rev counter
The rev counter shows the running
turnover of the engine so that the rider
can keep it within the ideal power range
Coolant temperature gauge
Shows the coolant temperature in °F
(Fahrenheit) or C°(Celsius).
If the coolant temperature gauge begins
to flash, stop the vehicle and run it at a
minimum until the temperature of the
coolant drops.
If the temperature does not drop, switch
off the engine.
Digital clock
Shows the time in hours and minutes.
Digital clock setting
Press and hold down the ”RESET“
button for 3 seconds until the reading
begins to flash.
Adjust the hour by pressing the
“SELECT” button.
Press the ”RESET“ button to pass on to
adjust the minutes (tens and then units).
Adjust the minutes by pressing the
”SELECT“ button.
Press the “SELECT” button again to
quit.
Fuel gauge
The digital fuel gauge shows the capaci-
ty of the fuel tank. As the fuel level
drops, the lines on the gauge will
become closer and closer to the "E"
reserve area. As soon as the final line
starts to flash, there is an autonomy of
about 3 litres of fuel.
Speedometer
Indicates the vehicle's speed in km/h or
mph. To pass from one to the other,
press the SELECT” button.
Benelli TNT25 Owner's Manual
http://www.motorcycle.in.th

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Benelli TNT25 and is the answer not in the manual?

Benelli TNT25 Specifications

General IconGeneral
Displacement249.2 cc
Bore x Stroke72 mm x 61.2 mm
Compression Ratio11.2:1
Starting SystemElectric
Transmission6-speed
ClutchWet multi-plate
Front Brake280 mm Disc
Front Tire110/70 - 17
Rear Tire150/60 - 17
Length x Width x Height2080 mm x 810 mm x 1125 mm
Seat Height780 mm
Wheelbase1400 mm
Kerb Weight159 kg
Engine TypeSingle Cylinder, 4 Stroke, Liquid Cooled
Maximum Torque21.6 Nm @ 8000 rpm
Fuel SystemElectronic fuel injection
IgnitionECU
Frame TypeSteel trestle
Front SuspensionUpside Down Telescopic Forks
Rear SuspensionHydraulic Monoshock
ABSNo
