Benelli TNT25 User Manual

COMANDI PRINCIPALI
81
EN
MAIN CONTROLS
1
2
CLUTCH LEVER
The clutch lever is located on the dial on
the left of the handlebar. To release the
clutch, pull the lever towards the dial.
To engage the clutch, release the lever.
To guarantee good clutch action, pull
the lever quickly and release it slowly.
To adjust the clutch lever, see the
maintenance chapter.
BRAKE LEVER
The brake lever is located on the dial on
the right of the handlebar.
To engage the front brake, pull the lever
towards the dial.
The brake lever has a position
adjustment knob "1".
To adjust the distance between the
brake lever and the accelerator dial, turn
the knob clockwise or anticlockwise;
anticlockwise will move the lever closer,
while clockwise will move it further
away.
Make sure that the correct adjustment,
set from the adjustment gauge is in line
with the brake lever reference "2".
REAR BRAKE PEDAL
The brake pedal is on the right side of
the motorbike.
To enable the rear brake, press the
brake pedal.
CONTROLLI PRIMA DELLA GUIDA
Senza titolo-2 29 21/12/2015 15:49:57
Benelli TNT25 Owner's Manual
http://www.motorcycle.in.th

Benelli TNT25 Specifications

General

Displacement	249.2 cc
Bore x Stroke	72 mm x 61.2 mm
Compression Ratio	11.2:1
Starting System	Electric
Transmission	6-speed
Clutch	Wet multi-plate
Front Brake	280 mm Disc
Front Tire	110/70 - 17
Rear Tire	150/60 - 17
Length x Width x Height	2080 mm x 810 mm x 1125 mm
Seat Height	780 mm
Wheelbase	1400 mm
Kerb Weight	159 kg
Engine Type	Single Cylinder, 4 Stroke, Liquid Cooled
Maximum Torque	21.6 Nm @ 8000 rpm
Fuel System	Electronic fuel injection
Ignition	ECU
Frame Type	Steel trestle
Front Suspension	Upside Down Telescopic Forks
Rear Suspension	Hydraulic Monoshock
ABS	No
