CONTROLLI PRIMA DELLA GUIDA
IMPORTANT NOTICE:
WEAR LIMIT
-
h
9/10 h
10 m
CHECKS BEFORE RIDING
Senza titolo-2 29 21/12/2015 15:49:57
TYRE CHECK
Use a gauge to check the pressure.
Pressure should be measured while
tyres are cool.
Tyre pressure
Front tyre: 2.4 bar
Back tyre: 2.4 bar
• Make sure that there are no fragments
of metal, nails or gravel in the tyre
tread. Remove if necessary.
• Check for wear. Replace tyres if the
wear is excessive or irregular. The
depth limit for tread is:
Front tyre: 1.6 mm
Back tyre: 1.6 mm
Incorrect pressure, or excessive or
irregular wear to tyres will reduce vehi-
cle stability.
HEAD LIGHT CHECK
With the engine running, check the
correct operation of positioning lights,
front and back, the strong and dipped
headlights and the numberplate light.
Headlamp adjustment
Sit on the vehicle at a distance of 10
metres from a wall. Switch on the high
beam and measure the maximum height
of the lit area.
• Standard height from ground level:
9/10 total height
Benelli TNT25 Owner's Manual
http://www.motorcycle.in.th

Benelli TNT25 Specifications

General

Displacement	249.2 cc
Bore x Stroke	72 mm x 61.2 mm
Compression Ratio	11.2:1
Starting System	Electric
Transmission	6-speed
Clutch	Wet multi-plate
Front Brake	280 mm Disc
Front Tire	110/70 - 17
Rear Tire	150/60 - 17
Length x Width x Height	2080 mm x 810 mm x 1125 mm
Seat Height	780 mm
Wheelbase	1400 mm
Kerb Weight	159 kg
Engine Type	Single Cylinder, 4 Stroke, Liquid Cooled
Maximum Torque	21.6 Nm @ 8000 rpm
Fuel System	Electronic fuel injection
Ignition	ECU
Frame Type	Steel trestle
Front Suspension	Upside Down Telescopic Forks
Rear Suspension	Hydraulic Monoshock
ABS	No
