Benelli TNT25 - Rear Shock Absorber Adjustment

85
EN
MAIN CONTROLS
REAR SHOCK ABSORBER
IMPORTANT NOTICE:
Senza titolo-2 22 21/12/2015 15:49:53
A
D
C
B
Spring pre-load adjustment
The rear shock absorber is fitted with an
adjustment ring nut for the pre-load of
spring “A" and a return ring nut "D".
Adjust the spring pre-load as follows:
To increase the spring's preload and
therefore make the suspension more
rigid, turn the adjustment ring nut “A” in
direction (B).
To reduce the spring's preload and
therefore make the suspension softer,
turn the adjustment ring nut “A” in
direction (C).
At the end of the adjustment, tighten the
return ring nut (D).
To avoid damaging the mechanism, do
not try turning over the maximum or
minimum setting.
Always have the shock absorber
adjusted by a Benelli assistance
centre.
Benelli TNT25 Owner's Manual
