Benelli TNT25 User Manual

74
EN
� IMPORTANT:
VEHICLE IDENTIFICATION
VEHICLE IDENTIFICATION
We advise you to keep a copy of the
identification number (ID) of the engine
and frame and the model name:
Engine number (1).................................
Frame number (2):................................
Label (3):................................................
Any changes to the ID number stamped
on the frame or engine will automatically
render the warranty null and void.
Engine number: The number is
punched on the engine casing, to the left
side of the rider and is the construction
serial number of the engine.
Frame number:
The identification number of the vehicle is
punched on the steering head; this
number is registered with the relevant
authorities for the area concerned.
Engine number (1)
Frame number (2)
Label:
The label of the model is applied to the left
side of the steering head. This information
is needed when ordering spares from
Benelli dealers.
Label (3)
Senza titolo-2 29 21/12/2015 15:49:57
Benelli TNT25 Owner's Manual
http://www.motorcycle.in.th

Benelli TNT25 Specifications

General

Displacement	249.2 cc
Bore x Stroke	72 mm x 61.2 mm
Compression Ratio	11.2:1
Starting System	Electric
Transmission	6-speed
Clutch	Wet multi-plate
Front Brake	280 mm Disc
Front Tire	110/70 - 17
Rear Tire	150/60 - 17
Length x Width x Height	2080 mm x 810 mm x 1125 mm
Seat Height	780 mm
Wheelbase	1400 mm
Kerb Weight	159 kg
Engine Type	Single Cylinder, 4 Stroke, Liquid Cooled
Maximum Torque	21.6 Nm @ 8000 rpm
Fuel System	Electronic fuel injection
Ignition	ECU
Frame Type	Steel trestle
Front Suspension	Upside Down Telescopic Forks
Rear Suspension	Hydraulic Monoshock
ABS	No
