MAINTENANCE
10.0-15.0 mm
AC
IMPORTANT NOTICE:
Senza titolo-2 38 21/12/2015 15:50:01
CHANGING COOLANT
Change cooling fluid at the intervals
specific in the periodical maintenance
and lubrication sheet. Have the coolant
changed by an Authorised Benelli
Dealer.
Never try to remove the radiator cap
when the engine is hot
1) Loosen the clutch ring nut “A” and the
clutch screw “C” on the cable, at the
same time.
2) To increase clutch lever backlash,
turn the clutch screw “C” clockwise
(seen from sitting on the bike).
To reduce the clutch lever backlash,
turn the clutch screw “C” anticlockwise
(seen from sitting on the bike).
3) After adjusting, tighten the clutch ring
nut “A”.
SPARK PLUG INSPECTION
Since the spark plug replacement and
check may be difficult for an operator
with little experience, we recommend
contacting an authorised Benelli
workshop.
CLUTCH BACKLASH
ADJUSTMENT
The clutch lever backlash needs to be
10.0-15.0 mm as shown in the figure.
Check the clutch lever backlash regular-
ly and adjust as necessary:
